PRATICA PUBLIC, lift station
Lifting stations are used to convey wastewater to final destinations that are located higher and some distance from the drainage points.
One-piece polyethylene Lift Station with discharge connections for public sewers.
| Note : | Pumps with single-channel impeller. Supplied with level regulator, control panel, ball valves and non-return valves in pairs designed for free-standing installation. Optional: visual/acoustic alarm, remote control. Compliance with standard: 2006/42/CE - 2004/108/CE - 2006/95/CE |
| Applicazione : | Lifting stations are used to convey wastewater to final destinations that are located higher and some distance from the drainage points. |
| Codice | D (cm) | Altezza H (cm) | ØE (mm) | Potenza pompa (Kw) | Capacità (litri) | Tensione (V) | Portata Q (m3/h) | Mandata | Articolo | Prevalenza H (m) |
|---|---|---|---|---|---|---|---|---|---|---|
| IS04600 | 160 | 200 | 200 | 1,1 | 3.000 | 380 | 0 - 42 | 2 | 3000 B2 | 2 - 15 |
| IS04601 | 160 | 200 | 200 | 1,1 | 3.000 | 380 | 0 - 36 | 2 | 3000 E2 | 2 - 11 |
| IS04602 | 160 | 200 | 200 | 2,6 | 3.000 | 380 | 0 - 12,5 | 1½ | 3000 R2 | 4 - 21 |
| IS04603 | 160 | 240 | 200 | 1,5 | 4.000 | 380 | 0 - 48 | 2 | 4000 B2 | 3 - 18 |
| IS04604 | 160 | 240 | 200 | 1,5 | 4.000 | 380 | 0 - 42 | 2 | 4000 E2 | 2 - 13 |
| IS04605 | 160 | 240 | 200 | 2,6 | 4.000 | 380 | 0 - 12,5 | 1½ | 4000 R2 | 4 - 21 |
| IS04606 | 160 | 280 | 200 | 2,2 | 5.000 | 380 | 0 - 54 | 2 | 5000 B2 | 5 - 20 |
| IS04607 | 160 | 280 | 200 | 2,2 | 5.000 | 380 | 0 - 48 | 2 | 5000 E2 | 3 - 17 |
| IS04608 | 160 | 280 | 200 | 2,6 | 5.000 | 380 | 0 - 12,5 | 1½ | 5000 R2 | 4 - 21 |
