The New F6.50 Flow Transmitter is a rotor-based device that can be used for the measurement of any type of solid-free liquid.
The F6.50 Flow Transmitter provides a 4-20 mA range output and is equipped with Bluetooth® connection for interaction with our Aliaxis Smart Connect App. This allows the user to set the transmitter's configuration, instal parameters and other features.
The specific design ensures precise flow measurements for various pipe sizes, from DN15 (0.5") to DN600 (24").
The Smart Connect App
The New F6.50 Flow Transmitters' series are able to communicate with the user via Bluetooth® connection through the Smart Connect App.
Smart Connect allows the user to interact with the transmitter quickly and easily to access the instrument's settings or for a proximity reading of the information detected during its use.
What are the main features of the Smart Connect App?
- Maximum signal range: 10m, even in the presence of obstacles
- Installation parameters setting: material and size of the pipe, K-factor
- Protection of settings access, via user password
- Multilingual interface
- Reading of the instantaneous and totalized flowrate, and related current output value
- Auto flow rate calibration
- Measurement units setting, filters, and measurement percentage correction
- Setting of the flow measurement range corresponding to the 4-20mA range
- Simulation of current values for evaluation of calibration and linearity of output
- Data logger
The Smart Connect App is compatible with Android and iOS.
APPLICATIONS:
- Industrial Water and Wastewater Treatment
- Water cooling systems
- Swimming pools
- Flow control and monitoring
- Water regeneration plants
- Processing & Manufacturing Industry
- Water distribution
- Irrigation and agricolture
MAIN FEATURES:
- High chemical resistance
- Pipe size range: DN15 (0.5") to DN600 (24")
- Low pressure drop
- Setting of the instrument's functional parameters and proximity reading of the information detected during its use, via the Aliaxis Smart Connect App
- 4-20 mA signal transmission via cable connection
Download
