Manhole cover and drain for floor shower with MAGNETECH siphon system
![Sistema di sifonatura Magnetech chiusino DOCIA-XS per doccia](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Chiusino-DOCIA-XS.png)
![Sistema di sifonatura Magnetech TURBOFLOW-XS piletta per piatto doccia](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-piletta-doccia-sifonanate-TURBOFLOW-XS.jpg)
What is the Magnetech siphon system?
3 magnets to block the reflux of bad smells.
The innovative system is equipped with 3 magnets, with opposite charges, which ensure maximum efficiency allowing maximum water outflow and preventing the backflow of bad odors or the emptying of the siphon.
![Sistema Magnetech doccia perfetta](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Sistema-Magnetech-Doccia.png)
Lowered manhole cover for shower DOCIA-XS / Magnetech
Innovative system, 3 magnets that allow maximum outflow of water, preventing the backflow of bad smells or the emptying of the siphon.
![Sistema di sifonatura Magnetech chiusino DOCIA-XS per doccia a pavimento](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Chiusino-DOCIA-XS-esploso.jpg)
![Punto di forza del sistema di sifonatura Magnetech: 3 magneti per azionare la sifonatura](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Chiusino-doccia-3-magneti.jpg)
Maximum versatility with the tileable grate
Two models available:
- Classic design grill in stainless steel
- Stainless steel tileable container grate
- for endless versatility according to the surrounding colors and shapes.
![](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-chiusino-versione-griglia.jpg)
A technology that can be adapted to any type of shower tray, ensuring ease of maintenance and maximum sealing
![](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-chiusino-DOCIA-XS-bagno.jpg)
HIGH CAPACITY
![Sistema Magnetech portata elevata sifone doccia](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-portata-elevata-sifone-doccia.png)
The water from the shower exerts a pressure which opens the siphon plate and allows drainage. The more the flux increases, the greater the opening of the magnetic plate will be.
MAXIMUM FLOW RATE 36 l/min
MAXIMUM HOLD
![Sistema Magnetech anti-intasamento sifone doccia](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-anti-intasamento-sifone-doccia.png)
During the shower the valve remains in suspension, no hair attachment areas or residues. When the water flow decreases, the magnetic force brings the pan back to the closed position, filling up with water. A 1 cm water head is formed which acts as a second siphon.
STOP BAD SMELLS
![Sistema Magnetech stop cattivi odori doccia sifone](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-stop-cattivi-odori-doccia-sifone.png)
The magnetic force keeps the plate hermetically closed. The magnetic siphon system combined with the water head ensures total sealing and prevents the backflow of bad odors and the emptying of the siphons.
Why choose the DOCIA-XS / Magnetech manhole cover?
![Punto di forza del sistema di sifonatura Magnetech: doppia sifonatura](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-doppia-sifonatura.png)
Double siphon
Magnetic siphon + Siphon with 1cm head of water
![Punto di forza del sistema di sifonatura Magnetech: ultra compatto](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Ultra-Compatto.png)
Ultra compact
Can be installed in any condition thanks to the minimum size 60mm
![Punto di forza del sistema di sifonatura Magnetech: griglia contenitore piastrellabile](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Piastrellabile.png)
Tileable
Available in the version with tileable container for design finishes.
![Punto di forza del sistema di sifonatura Magnetech: ispezionabile](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-ispezionabile.png)
Inspectable
Completely and easily inspectable thanks to the removable siphon system.
![Punto di forza del sistema di sifonatura Magnetech: stop cattivi odori proveniente dal sifone dalla doccia](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-chiusino-stop-cattivi-odori.png)
Stop bad smells
No more bad smells with the Magnetec anti-reflux system
![Punto di forza del sistema di sifonatura Magnetech: alta portata d'acqua](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Portata-Eccezionale.png)
Exceptional range
Guarantees rapid drainage and prevents deposits of encrustations (36 l/min).
![Punto di forza del sistema di sifonatura Magnetech: sicuro con le guarnizioni bi-iniettate](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-chiusino-Magnetech-Sicurezza.png)
Resistant and safe
Provided with bi-injected gaskets to ensure maximum sealing and adapt to any surface.
![Punto di forza del sistema di sifonatura Magnetech: rapida rimozione della griglia per un eventuale ispezione](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Rimozione-Rapida.png)
Quick removal
Easy removal of the grate thanks to the pressure lift system.
Waste for shower trays TURBOFLOW-XS / Magnetech
Waste for shower tray with new Magnetech siphoning system.
Solution for plate with Ø 90 hole and thickness from 6mm to 25mm.
![Aliaxis-IT chiusino Turboflow-XS piatto doccia con sifonatura Magnetech](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-TurboflowXS-chiusino.png)
![Punto di forza del sistema Magnetech: 3 magneti per azionare la sifonatura](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-piletta-doccia-3-magneti.jpg)
Sophisticated simplicity for any type of Ø90 shower tray
![piatto doccia con piletta Magnetec](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis.Italia-piletta-Magnetech-ambiente-bagno.jpg)
Opposites attract
Compact drain with anti-odour magnetic plate for shower tray.
SAFE: equipped with a bi-injected gasket to ensure maximum sealing and adapt to any surface.
![](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-piletta-TurboFlowXS-componenti.jpg)
Why choose the TURBOFLOW-XS / Magnetech drain?
![Punto di forza del sistema di sifonatura Magnetech: doppia sifonatura](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-doppia-sifonatura.png)
Double siphon
Magnetic siphon + Siphon with 1cm head of water
![Punto di forza del sistema di sifonatura Magnetech: alta portata d'acqua](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Portata-Eccezionale.png)
Exceptional range
Guarantees rapid drainage and prevents deposits of encrustations (36 l/min).
![Punto di forza del sistema di sifonatura Magnetech: compatto](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Compatto.png)
Ultra compact
Can be installed in any condition thanks to the minimum size 66mm
![Punto di forza del sistema di sifonatura Magnetech: ispezionabile](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-ispezionabile.png)
Inspectable
Completely and easily inspectable thanks to the removable siphon system.
![Punto di forza del sistema di sifonatura Magnetech: stop cattivi odori proveniente dal sifone dal piatto doccia](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-piletta-stop-cattivi-odori.png)
Stop bad smells
No more bad smells with the Magnetec anti-reflux system
![Punto di forza del sistema di sifonatura Magnetech: altissima durata dei materiali nel tempo](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Resistente.png)
Resistant
The high quality materials guarantee great resistance and durability.
![Punto di forza del sistema di sifonatura Magnetech: adattabilità](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-Magnetech-Adattabile.png)
Adaptable
Adjustable extension for Ø90 hole shower trays with variable thickness from 6mm to 25mm
![Punto di forza del sistema di sifonatura Magnetech: sicuro con le guarnizioni bi-iniettate](/website/aliaxis-it/LANDING%20PAGES%20%26%20FOCUS%20ON/Magnetech/Aliaxis-IT-piletta-Magnetech-Sicurezza.png)
Safe
Provided with bi-injected gaskets to ensure maximum sealing and adapt to any surface.
Get to know the Magnetech siphon system
DOCIA-XS / Magnetech manhole cover
TurboFlow-XS / Magnetech drain
Tutorial on how to install the floor drain for MAGNETECH showers
